Description

(1) The pneumatic press can accommodate stamping capacities from 200 to 1000 kg.
(2) The forged C-type structure provides excellent rigidity, ensuring durability and easy, safe operation.
(3) The descending speed, opening height (distance), and stroke can be adjusted freely.
(4) The standard die head size is ψ20, with an option for ψ38.
(5) A dedicated movable fixed worktable with hidden wheels facilitates easy mobility and stability.
(6) Suitable for bearing insertion and stamping/riveting of small objects.
(7) Control options allow switching between manual and automatic modes, making installation, calibration, and pressure hold time adjustments convenient.

Optional Accessories

• Safety light curtain and acrylic protective guard.
• Movable fixed worktable.

Scope of application:

• Punching.
• Cutting.
• Riveting.
• Bearing insertion.
• PE sheet cutting.
• Component assembly.

Applicable industries:

• Hand Tools Industry.
• Cosmetics Industry.
• Electronics and Optoelectronics Industry.
• Bicycle Manufacturing Industry.
• Fitness Equipment Manufacturing Industry.
